MAG500-220S24 500W 220VAC to 24VDC AC-DC Power Module for Medical Equipment Power Systems

Modern medical equipment such as electric operating tables, rehabilitation devices, patient care systems, and auxiliary medical electromechanical equipment require stable and reliable 24V DC power supplies for safe and continuous operation.

The MAG500-220S24 AC-DC power module from Guangdong Mingzinc Technology converts 176–264VAC input into stable 24VDC output, providing high reliability, electrical isolation protection, and IP65 environmental resistance for medical equipment power systems.

Why Medical Equipment Requires Reliable 24V AC-DC Power Modules

Medium-sized medical devices commonly require:

Stable 24V DC actuator control power
Reliable motor drive auxiliary power
Low ripple output for control electronics
High isolation protection for patient safety
Continuous 24/7 operation capability

The MAG500-220S24 meets these medical-grade industrial power requirements.

Key Specifications of MAG500-220S24

Model: MAG500-220S24
Rated Power: 500W
Input Voltage: 176–264VAC
Output Voltage: 24VDC
Output Current: 20.83A
Cooling Method: Natural Cooling with Aluminum Heat Sink Housing
Protection Level: IP65
Safety Standards: UL1950 / IEC950
Dimensions: 200 × 158 × 72 mm

Optional power range available:

400W–600W
Multi-output customization supported

Typical Applications in Medical Equipment Systems

The MAG500-220S24 is widely used in:

Electric operating tables
Rehabilitation training equipment
Medical patient care devices
Medical lifting actuator systems
Medical auxiliary control platforms
Electromechanical medical equipment

Key Technical Advantages

Wide AC Input Voltage Range

Supports 176–264VAC input range

Ensures stable operation under hospital grid fluctuations.

Inrush Current Suppression Circuit

Reduces startup surge current

Improves equipment reliability

Extends system lifetime

Low Ripple and Noise Output

Integrated EMI filtering improves stability of medical control electronics.

High Electrical Isolation Protection

Protects downstream equipment

Improves safety performance of medical systems

Protection Features

Input undervoltage protection
Over-temperature protection
Output overcurrent protection
Short circuit protection

Ensures reliable long-term operation.

IP65 Aluminum Housing for Medical Equipment Installation

Fully sealed aluminum enclosure provides:

Dust protection
Moisture resistance
Water spray resistance

Suitable for internal installation inside medical equipment systems.

Customization Support from Mingzinc Technology

We provide:

Voltage customization
Power level customization
Mechanical structure customization
Multi-output configuration
OEM / ODM services

Contact Mingzinc Technology for Datasheet

If you are designing medical equipment power systems and need a reliable 500W 24V AC-DC power module, contact Mingzinc Technology for technical support and datasheets.
