Empowering the Future: Modular Power Supply Solutions for Advanced Battery Applications

1. Analysis of China’s Battery Export Volume (2022–2024)

China has solidified its position as the world’s largest producer and exporter of batteries over the past decade. From 2022 through the first nine months of 2024, Chinese battery shipments continued to surge—driven largely by electric vehicles (EVs), portable electronics, and energy storage projects. Below is a breakdown of export volumes, top destination markets, and shifts in battery types and applications.

1.1 Overall Export Figures (2022–2024)

• 2022: China’s lithium-ion battery exports reached approximately USD 50.9 billion, marking an 86.7 percent year-over-year increase compared to 2021. Rapid EV adoption in Europe, North America, and Asia, combined with demand for grid-scale storage and consumer electronics, fueled this growth.

• 2023: Export value climbed to roughly USD 65 billion, a near 28 percent rise over 2022. In value terms, European markets absorbed over 40 percent of shipments, with Germany and the Netherlands emerging as major importers.

• Jan–Sept 2024: Through September 2024, Chinese lithium-ion battery exports totaled USD 43.7 billion, a 10.1 percent drop year-over-year. Nevertheless, unit shipments increased by 4.6 percent to 2.85 billion cells/modules, reflecting sustained volume growth despite modest value contraction, driven by gradual price declines and product-mix shifts.

1.2 Top Three Destination Markets: Industry Demand Analysis
China’s battery exports are highly concentrated. In early 2024, the top three importers by export value were the United States (23.1 percent), Germany (18.1 percent), and Vietnam (6.2 percent). Below is an overview of each market’s driving factors:

• United States

  • Electric Vehicles: U.S. EV production—led by Tesla, GM, Ford, Rivian, and startups—has skyrocketed. Automakers rely on Chinese cellmakers for cylindrical, prismatic, and pouch cells that form the backbone of battery packs. Meanwhile, major gigafactories in Nevada, Texas, and elsewhere still import significant quantities of Chinese cells for initial production ramp-ups.

  • Grid-Scale Energy Storage: Utilities and independent power producers invest heavily in frequency regulation, peak shaving, and renewable integration. Chinese battery modules (often assembled from domestically produced pouch and cylindrical cells) supply large megawatt-scale systems.

  • Consumer Electronics: Smartphones, laptops, tablets, and power tools remain staples of U.S. battery imports. High-energy-density pouch cells and battery packs for portable gadgets account for a sizeable share of shipments.

• Germany

  • EV and Automotive Sector: Germany’s push toward carbon-neutral transportation (the “Energiewende” ethos) has driven massive EV adoption. Major automakers (Volkswagen, BMW, Mercedes-Benz) integrate Chinese prismatic and pouch cells into battery packs.

  • Stationary Storage & Renewables: Germany leads Europe in rooftop solar installations and utility-scale renewables. Battery storage systems—ranging from residential solar+storage to commercial microgrids—often rely on Chinese modules.

  • Industrial & Backup Power: Data centers, hospitals, telecom facilities, and manufacturing plants frequently deploy both valve-regulated lead-acid (VRLA) and lithium-ion battery modules sourced from China for uninterruptible power supply (UPS) and backup systems.

• Vietnam

  • Electronics Manufacturing Hub: Vietnam’s booming smartphone, tablet, and wearable electronics factories (e.g., by Samsung, LG, Xiaomi) require massive quantities of pouch cells and battery packs. Chinese battery manufacturers often co-locate production near or within Vietnamese facilities to streamline logistics.

  • E-Two-Wheelers: Rising consumer spending and government incentives have accelerated adoption of electric motorcycles and scooters. Battery modules—typically prismatic or cylindrical Li-ion cells—arrive from China and are assembled locally into e-two-wheeler packs.

  • Emerging Home & Commercial Storage: As Vietnam expands its rooftop solar footprint, small- to mid-scale battery modules (assembled from Chinese cells) supply local off-grid and grid-tied storage projects in rural and peri-urban areas.

  •

  •

1.3 Battery Types & Applications in Top Three Markets

• United States

  • Cylindrical & Prismatic Li-ion Cells – Predominantly used in EV battery packs (Tesla’s 2170 and 4680 formats, GM’s Ultium system). Cylindrical formats remain popular for gigafactory production ramp-ups, while prismatic cells support high-capacity EV platforms.

  • Pouch Cell Modules – Widely adopted for grid-scale storage (e.g., Tesla Megapack alternatives, LG Chem/ CHEP systems). Multi-kWh rack-based modules built from pouch cells help utilities manage renewables integration.

  • Consumer Electronics Packs – High-energy-density pouch cells for smartphones (Samsung Galaxy, Apple iPhone), laptops (Dell, HP), power tools (Milwaukee, DeWalt).

• Germany

  • Prismatic Li-ion Cells – Integrated into Volkswagen ID series, BMW iX, Mercedes EQ platforms. Prismatic cells provide a balance of energy density, mechanical rigidity, and thermal management.

  • Pouch & Cylindrical for Stationary Storage – Systems from Sonnen, E3/DC, and other German integrators often source Chinese pouch modules for residential storage; cylindrical cell-based containers serve larger commercial/industrial projects.

  • Backup & UPS Batteries – VRLA (AGM and Gel) modules and Li-ion rack solutions by Chinese OEMs support data centers (e.g., Deutsche Telekom, SAP), telecommunications (e.g., Deutsche Telekom, Vodafone DE), and critical infrastructure.

• Vietnam

  • Pouch Cells for Consumer Electronics – Local assemblers of smartphones, tablets, and IoT devices rely on high-capacity pouch cells shipped from China.

  • Prismatic & Cylindrical Li-ion for E-Scooters & E-Motorcycles – Battery module suppliers send prismatic 18650/21700 cells and small prismatic pouch cells to Vietnamese pack assemblers, fueling electric two-wheel mobility.

  • Small-Scale Storage Modules – Chinese battery integrators supply 1–10 kWh residential energy storage units (ESUs) to solar installers, enabling grid stability and self-consumption.

2. Application of Modular Power Supply in Battery Systems

In modern battery systems—whether for EVs, stationary storage, or consumer electronics—a reliable, high-performance power source is essential for charging, testing, balancing, and maintaining battery health. Modular power supplies (also known as power modules or DC-DC converters) offer flexibility, efficiency, and precise control compared to traditional linear or monolithic power solutions. The following sections explore the requirements of modular power supplies for different battery chemistries, as well as potential pitfalls if modular solutions are not used.

2.1 Requirements of Modular Power Supplies for Different Battery Types

1. Lithium-Ion Batteries (Li-ion)

   • CC-CV Charging Profile: Li-ion cells must be charged using a precise constant-current, constant-voltage (CC-CV) algorithm. A modular power supply must provide programmable output current and voltage stages to follow the Li-ion charge curve (e.g., charging at a constant 0.5 C to 1 C rate until reaching the configured voltage cutoff, then tapering to maintain voltage).

   • High Efficiency & Low Output Ripple: Since Li-ion cells are sensitive to voltage fluctuations, the power module should achieve ≥ 95 percent efficiency at typical operating points and maintain ripple below 50 mV p-p. Low electromagnetic interference (EMI) is also crucial to prevent battery management system (BMS) errors.

   • Protection & Monitoring Features: Integrated overvoltage protection (OVP), overcurrent protection (OCP), temperature monitoring (e.g., NTC/NTC-based or thermocouple feedback), and short-circuit protection are mandatory. Some advanced modules offer cell-level balancing outputs and real-time telemetry via communication interfaces (I²C, PMBus, CAN, or Modbus).

   • Wide Input Voltage Range: For bench-top charging rigs or manufacturing test stations, a module should accept 90–265 VAC (for universal AC-DC input) or a wide DC input (e.g., 36–75 VDC), accommodating variations in line voltage or upstream bus voltage.

   •

   •

2. Lead-Acid Batteries (Flooded, AGM, Gel)

   • Multi-Stage Charging Algorithm: Lead-acid batteries benefit from a three-stage charge: bulk (constant current), absorption (constant voltage), and float (lower constant voltage). A modular power supply should support configurable setpoints for each stage (e.g., Bulk at 14.4 V, Absorption at 14.7 V, Float at 13.5 V for a 12 V battery) and smoothly transition between them.

   • Soft-Start & Input Filtering: Lead-acid banks can draw high inrush currents upon initial connection. A module with soft-start limits peak inrush to avoid tripping upstream breakers and includes input EMI filtering (CISPR compliance) to reduce harmonic distortion on the AC mains.

   • Temperature Compensation: Especially for large stationary VRLA installations (e.g., telecom shelters or solar farms), charging voltages must be adjusted based on ambient temperature (typically –0.3 mV/°C per cell) to prevent overcharging or undercharging. Modules with integrated temperature sensor inputs simplify implementation.

   • Wide Operating Temperature Range & Robustness: Industrial or outdoor installations require modules rated for –20 °C to +70 °C, with conformal coating or high IP (≥ 20) for dust and moisture resistance.

3. Nickel-Metal Hydride (NiMH) & Nickel-Cadmium (NiCd)

   • Delta-V/Peak-Voltage Detection: NiMH/NiCd cells require a negative delta-V or peak-voltage detection method to terminate charging, in addition to a timer or dV/dt approach. The power supply must deliver constant current and monitor voltage slope precisely (± 1 mV resolution) to detect cell saturation.

   • Adaptive Charging Profiles: Some high-end NiMH chargers apply a multi-stage approach (e.g., a fast charge at 1 C until voltage peak, then trickle charge at C/10). A programmable module must allow custom algorithms to be implemented in tandem with a BMS or microcontroller.

   • Safety Protections: Overtemperature shutdown (for NiMH/NiCd, which produce heat during charging), reverse polarity protection, and cell-level monitoring circuits are essential. Efficiency is less critical than Li-ion or lead-acid, but modules still benefit from ≥ 90 percent efficiency to reduce wasted heat.

4. Emerging & Specialty Chemistries (LiFePO₄, Solid-State, Flow Batteries)

   • Custom Voltage Setpoints & Balancing: LiFePO₄ cells have a nominal voltage of 3.2 V per cell and require a charge cutoff around 3.6 V. Modules must be configurable to non-standard voltage ranges and offer cell balancing outputs if the battery management system is external.

   • High-Voltage Stacks: Some solid-state or flow battery test platforms operate at several hundred volts. Modular DC-DC or AC-DC supplies rated for 400 V to 800 V input/output may be needed. Safety outlines (isolation of ≥ 2 kV DC, reinforced insulation) and compliance with IEC 61010-1/UL 61010 standards become critical.

           The Key Role of Modular Power Supplies in Industrial Control for Automotive Production

2.2 Impacts on Batteries When Not Using a Modular Power Supply
Opting for a non-modular (e.g., linear transformer-based or off-the-shelf bench power supply) solution can have several detrimental effects:

1. Imprecise Charging Profiles

   • Undercharging/Overcharging Risk: Without precise CC-CV or multi-stage algorithms, Li-ion cells risk overvoltage stress (accelerating capacity fade, increasing internal resistance, and raising thermal runaway risk). Lead-acid batteries may never reach full absorption or float charge stages, leading to sulfation and reduced cycle life.

   • Poor Charge Efficiency: Linear power supplies dissipate excess voltage as heat, leading to lower overall charging efficiency (often 50–70 percent), higher operating temperatures, and greater cooling requirements.

2. Lack of Protections

   • No Integrated OVP/OCP/OTP: Generic power sources rarely include battery-specific protections. A short circuit, cell imbalance, or thermal runaway event cannot be detected or mitigated in real time, increasing fire and safety hazards.

   • No Real-Time Monitoring or Telemetry: Absence of digital communications means no remote visibility into voltage, current, or temperature. Early signs of battery degradation or imbalance go unnoticed until catastrophic failure or capacity loss occurs.

3. Limited Flexibility & Scalability

   • Difficulty in Parallel or Series Expansion: Many bench power supplies cannot be paralleled or stacked safely to achieve higher current or voltage. For manufacturing or testing multiple battery strings simultaneously, this becomes a logistical burden, requiring multiple discrete units and complex wiring.

   • Poor Form Factor & Thermal Management: Traditional linear supplies are bulky, heavy, and generate significant heat, necessitating large enclosures and high airflow. In contrast, modular power supplies boast high power density, quiet operation, and a standardized package that simplifies rack or DIN-rail installations.

4. Higher Total Cost of Ownership (TCO)

   • Maintenance & Downtime: Modules designed for battery charging often include hot-swap or redundant-N+1 capabilities. If one module fails, it can be replaced without shutting down the entire system. Bench supplies or non-modular designs lack this, leading to longer outages and higher maintenance risk.

   • Inefficient Energy Use: Lower efficiency (especially under partial loads) translates to higher electricity bills and increased cooling costs—factors that add up significantly over the life of a battery-charging installation.

3. Types of Modular Power Supplies (Multi-Dimensional Introduction)

Modular power supplies come in diverse form factors, topologies, and feature sets to address the needs of different end-markets. Below is a multi-dimensional overview—organized by application, packaging, topology, and customization options—to guide engineers and procurement specialists in selecting the right solution.

3.1 How to Choose a Modular Power Supply for Different Applications

1. Industrial Automation & Telecommunications

   • Common Voltage Rails: 48 V DC – 12 V DC or 48 V DC – 5 V DC multi-output modules; often used for PoE switches, programmable logic controllers (PLCs), and remote radio units (RRUs).

   • Key Selection Criteria:

     • Redundancy & Hot-Swap: N+1 parallel operation ensures no single point of failure.

     • High MTBF: ≥ 500 000 hours (MIL-HDBK-217F).

     • Input Range: 36–75 V DC (accommodates battery float voltages in telecom shelters).

     • Cooling: Forced air or convection, depending on rack density and ambient temperature (0–55 °C).

     • Safety & EMC: Compliance with IEC 62368, EN 55032 (CISPR 32), and FCC Part 15.

2. Electric Vehicles & Energy Storage Systems

   • High-Power DC-DC Converters: Step down high-voltage battery packs (400–800 V) to 12 V or 48 V auxiliary bus for lighting, infotainment, thermal management, and BMS operation.

   • Key Selection Criteria:

     • Conversion Efficiency: ≥ 95 percent at full load to minimize heat generation.

     • Automotive/Transport Certifications: ISO 26262 (functional safety), AEC-Q100 (component qualification), UN R10 (EMC for vehicles).

     • Isolation & Safety: ≥ 2 kV DC isolation between input and output rails; reinforced insulation to withstand transients (± 1 kV surge).

     • Thermal Management: Wide operating temperature (–40 °C to +85 °C), with derating curves for high ambient applications.

3. Consumer Electronics & Telecom Equipment

   • Low-Power AC-DC & DC-DC Bricks: Common output voltages include 5 V, 9 V, 12 V, and 24 V. Typical power ratings range from 15 W (1/16 brick) up to 300 W (full brick).

   • Key Selection Criteria:

     • Low Output Ripple (< 50 mV p-p): Essential for sensitive digital circuits, RF communications, and audio applications.

     • Compact Size & Low Profile: 1/8 brick (2.28 × 1.44 × 0.4 in) or smaller to fit in dense chassis.

     • EMI/EMC: Must meet FCC Part 15 (Class B), CISPR 32/EN 55032 (Class B), and surge/ESD per IEC 61000.

     • Affordability: Price-to-performance ratio is critical; open-frame or encapsulated modules can reduce cost.

4. Solar & Renewable Energy

   • MPPT Controllers & Hybrid Inverters: While not a “power module” in the traditional sense, many off-grid or microinverter designs integrate modular DC-DC converters for maximum power point tracking (MPPT) and battery charging.

   • Key Selection Criteria:

     • Wide Input Voltage Range: 150–450 V PV input for string inverters; 12 V/24 V/48 V battery output.

     • Galvanic Isolation: Transformer-based or high-frequency isolated topologies to meet safety standards (UL 1741, IEC 62109).

     • Power Density: ≥ 800 W/in³ for rooftop microinverters.

     • Environmental Ratings: IP65–IP67 for outdoor units; extended temperature range (–25 °C to +60 °C).

3.2 Can Modular Power Supplies Be Customized?
Yes—customization is often essential when standard modules cannot meet specific voltage, current, form factor, or feature requirements. Common customization options include:

• Adjustable Voltage & Current Setpoints:

  • Many vendors provide trimmer pots or digital potentiometers (via I²C/PMBus) to tweak output voltage by ± 10 percent and current up to ± 20 percent. In highly specialized cases, the feedback network can be redesigned to produce entirely non-standard voltages (e.g., 13.8 V for telecom standby systems, 5.5 V for certain IoT gateways).

• Custom Output Connectors & Cabling:

  • Clients may request specific connector types (e.g., M8, Phoenix, Anderson Powerpole, or custom wiring harnesses) to match their in-house cabling standards.

  • Cable length, gauge, and shielding can be tailored to reduce voltage drop and EMI in long-run installations.

• Embedded Monitoring & Communications:

  • I²C, PMBus, SMBus, Modbus-RTU, CAN, or proprietary telemetry interfaces can be integrated, enabling remote health monitoring, real-time adjustment, and system-level energy management.

  • OLED/LCD status displays or multi-color LEDs showing output status, fault codes, and temperature warnings can be added for enhanced visual feedback.

• Mechanical & Environmental Adaptations:

  • Form Factor: Custom PCB outline or metal chassis for OEMs with unique space constraints (e.g., 1U rack height vs. DIN-rail modular blocks).

  • Cooling Solutions: Depending on airflow limitations, modules can be redesigned with heat sinks, heat pipes, or even embedded liquid-cooling cold plates. Conformal coating or ruggedized potting can improve resilience in harsh environments (marine, mining, desert).

  • Safety/Regulatory Certifications: Beyond CE and UL, customers can request IEC 60601 (medical), EN 62368 (audio/video/ICT), EN 61558 (safety of transformers), or ATEX/IECEx (explosive atmospheres).

3.3 What Makes a Modular Power Supply an Excellent Product
An outstanding modular power supply should excel across technical performance, reliability, safety, scalability, and service. The criteria below serve as a guideline for OEMs and purchasing teams:

1. High Conversion Efficiency

   • Full-Load & Light-Load Performance: ≥ 94 percent efficiency at full load and ≥ 90 percent at light load (10 percent–20 percent output). High efficiency reduces wasted heat, lowers operating costs, and minimizes cooling infrastructure.

2. Broad Input Voltage Range & Fast Load Transient Response

   • Wide Input Tolerance: Modules that accept 9–36 V, 18–75 V, 36–75 V, or higher DC inputs accommodate battery discharge curves, fluctuating bus voltages, or international AC mains variations (e.g., 85–264 VAC).

   • Fast Transient Response (< 30 µs): When load current steps from light to heavy in milliseconds (e.g., rack servers or telecom loads), the output must recover quickly without large overshoot or undershoot.

3. Comprehensive Protection Features

   • Overvoltage Protection (OVP)/Undervoltage Protection (UVP)

   • Overcurrent Protection (OCP)

   • Short-Circuit Protection (SCP)

   • Overtemperature Protection (OTP)

   • Overpower/Overload Protection (OPP/OLP)

   • Under-Temperature Lockout (UTL) or Cold-Start Inhibition (for batteries that should not be discharged below a threshold)

   • Modules should provide clear status indicators (LEDs or digital fault codes) and auto-restart logic or latch-off modes that can be remotely reset.

4. High Reliability & Longevity

   • MTBF (Mean Time Between Failures): ≥ 500 000 hours for telecom/industrial grade; ≥ 200 000 hours for cost-sensitive consumer/embedded products.

   • Quality Components: Use of capacitors rated at 105 °C or 125 °C, automotive-grade MOSFETs, X- and Y-class EMI capacitors, and winding tapes designed for high dielectric strength.

   • Rigorous Validation: Compliance with IEC 60068 (environmental testing), JESD22 (shock/vibration), and AEC-Q standards (for automotive variants).

5. Modularity & Expandability

   • Parallel/Redundant Operation: Hot-swap capability and current-share controllers enable seamless N+1 redundancy. Modules of the same model can be paralleled to scale up to multiple kilowatts without complex external balancing circuits.

   • Interchangeable Footprint: A product family with common form factor (e.g., 1/4 brick, 1/2 brick) allows manufacturers to stock a single chassis and easily swap modules to change voltage or power rating.

6. Thermal & Electromagnetic Design

   • Smart Thermal Management: Optimal heat sink design, airflow channels, and thermal interface materials ensure that modules can operate fan-less up to 50 °C or with minimal airflow in congested racks.

   • EMI/EMC Compliance: Designs should meet or exceed CISPR 22/EN 55022, FCC Part 15B, and industry-specific immunity standards (IEC 61000-4-2/3/4/5). Some high-end modules include optional EMI filters or shielded enclosures.

7. Robust After-Sales Service & Warranty

   • Warranty Terms: Standard 2–5 years depending on grade.

   • Global Technical Support: Field application engineers (FAEs) and local service centers to handle rapid troubleshooting, firmware updates, and replacement parts.

   • Spare Parts & Lifecycle Management: Availability of spares for ≥ 10 years, clear obsolescence roadmaps, and last-time buy options for long-life customers.

Our product testing（YouTube）

4. Conclusion

As global demand for cleaner energy, digitalization, and intelligent manufacturing accelerates, batteries (lithium-ion, lead-acid, NiMH, and emerging chemistries) continue to see unprecedented growth. In turn, modular power supplies—which offer precision charging, high efficiency, robust protections, and scalability—have become indispensable across applications ranging from electric vehicles and grid storage to telecom, industrial automation, and consumer electronics.

• For EV & Energy Storage Systems:
  Select high-power DC-DC converters or AC-DC battery chargers with ≥ 95 percent efficiency, automotive-grade certifications (ISO 26262, AEC-Q100), wide operating temperature (–40 °C to +85 °C), and reinforced isolation (≥ 2 kV). These modules ensure reliable auxiliary power rails and battery management, even under harsh environmental conditions.

• For Industrial Automation & Telecom Infrastructure:
  Prioritize modular 48 V → 12 V/5 V DC-DC supplies with N+1 redundancy, MTBF ≥ 500 000 hours, and input ranges of 36–75 V DC (to match battery float voltages). Hot-swap capability, wide temperature range (0–55 °C), and compliance with IEC 62368 and EN 55032 guarantee 24/7 operation in demanding facilities.

• For Consumer Electronics & Light IoT Applications:
  Utilize compact AC-DC bricks (15 W–300 W) that offer tight regulation (< 50 mV ripple), common global AC inputs (100–240 VAC), and minimal form factor (1/16 brick or 1/8 brick). EMI/EMC compliance (FCC Part 15, CE) and low BOM cost make these modules ideal for high-volume, cost-sensitive markets.

An excellent modular power supply addresses five core pillars: efficiency, reliability, protection, scalability, and service. By integrating precise charge algorithms, comprehensive fault management, and flexible packaging, modular power supplies extend battery lifespan, enhance system uptime, and reduce total cost of ownership (TCO).

If you are interested in customized solutions—such as custom voltage setpoints, embedded monitoring interfaces (I²C, PMBus, Modbus), or ruggedized enclosures—our engineering team is ready to collaborate. Whether you need a 12 V/100 A Li-ion charger for a manufacturing line, a 48 V → 12 V redundant telecom power shelf, or a series of AC-DC converters for IoT gateways, we can tailor a modular power supply to your exact specifications.
